4 J‐S180F/J‐S199F
Alicensedprofessionalshouldinstalltheappliance,
inspectit,andleaktestitbeforeuse.Thewarranty
willbevoidedduetoimproperinstallaon.
Theinstallershouldhaveskillssuchas:
• gassizing
• connecnggaslines,waterlines,valves,
electricity,
• knowledgeofapplicablenaonal,state,and
localcodes.
• installingvenngthroughawallorroof
Ifyoulacktheseskillscontactalicensedprofessional.
InstallaonInstrucons
InstallaonSteps
 PrepareforInstallaon......................................5
 DetermineInstallaonLocaon........................6
 ChecklisttoDetermineInstallaonLocaon...11
 MounttoWall..................................................11
 RemovetheFrontPanel..................................11
 InstallaonofVenng......................................12
 InstallaonofCondensateTrap.......................14
 ChecklistforVenngandCondensate .............14
 InstallaonofPlumbi
ng...................................15
 ChecklistforPlumbing.....................................17
 InstallaonofGasSupply................................17
 ConnectElectricity...........................................19
 AdjustforHighAltude...................................19
 ChecklistforGasandElectricity.......................19
 InstallaonofTem
peratureController............20
 FinalChecklist..................................................21
GeneralInstruconsInstallerQualificaons
DONOT
• Donotinstalltheapplia nce outdoors. 
• Donotinstalltheapplia nce inanareawherewater
leakageoftheunitorconneconswillresultin 
damagetotheareaadjacenttotheapplianceorto
lowerfloorsofthestructure.Whensuchlocaons
cannotbeavoided,itisrecommendedthata
suitabledrainpan,adequatelydrai
ned,beinstalled
undertheappliance.Thepanmustnotrestrict
combusonairflow.
• Donotobstructtheflowofcombusonand
venlaonair.Combusonairshallnotbe
suppliedfromoccupiedspaces.
• Donotusethisapplianceinanapplicaonsuchas
apoolorspaheaterthatuseschemicallytreated
water.(Thisapplianceissuitableforfillinglargeor
whirlpoolspatubswithpotablewa ter.) 
• Donotusesubstutepartsthatarenotauthorized
forthisappliance.
MUSTDO
• Theinstallaonmustconformwithlocalcodesor,
intheabsenceoflocalcodes,withtheNaonal
Fuel Gas Code, ANSI Z223.1/NFPA 54.Ifinstalledin
amanufacturedhome,theinstallaonmust
conformwiththeManufactured Home
Construcon and Safety Standard, Title 24 CFR,
Part 3280.
• Theappliance,wheninstalled,mustbeelectrically
groundedinaccordancewithlocalcodesor,inthe
absenceoflocalcodes,withtheNaonal Electrical
Code, ANSI/NFPA 70.
• Theapplianceanditsappliancemaingasvalve
mustbedisconnectedfromthegassupplypiping
systemduringanypressuretesngofthatsystem
attestpressuresinexcessof1/2psi(3.5kPa)
(13.84inW.C.).
• Theappliancemustbeisolatedfromthegassupply
pipingsystembyclosingitsindividualmanual
shutoffvalveduringanypressuretesngofthegas
supplypipingsystemattestpressuresequaltoor
lessthan1/2psi(3.5kPa)(13.84inW.C.).
TypeofInstallaon
• Forinstallaoninresidenalandcommercial
applicaons.
• Cerfiedforinstallaoninmanufactured(mobile)
homes.

Jacuzzi J?SN180F Specifications

General

Brand	Jacuzzi
Model	J?SN180F
Category	Water Heater
Language	English
