 J‐S180F/J‐S199F 21
FinalChecklist
□
Thewaterheaterisnotsubjecttocorrosive
compoundsintheair.
□ Thewatersupplydoesnotcontainchemicalsor
exceedstotalhardnessthatwilldamagetheheat
exchanger.
□ Clearancesfromthewaterheaterunitaremet.
□ Clearancesfromtheventterminaon/airintake
aremet.
□ Ensureyouhaveusedthecorrectvenng
productsforthemodelinstalledandthatyou
havecompletelyfollowedthevenng
manufacturer’sinstallaoninstruconsandthese
installaoninstrucons.
□ Verifythattheventsystemdoesnotexceedthe
maximumlengthforthenumberofelbowsused.
□ VerifythatswitchNo.1intheSW1DIPswitchhas
beenadjustedforventlengthifnecessary.Refer
tothesecononMaximumVentLength.
□ Verifythattheventpipehasadownwardslopeor
gradetotheoutsideof1/4inchperfoot(1.2º)
ORiftheventpipeisslopedtowardthewater
heater(assomelocalcodesrequire),thata
condensatecollectorisinstalledtoallow
condensaontodrainawayfromthewat
er
heatertoaproperdrainsource.
□ Verifythatcondensatewillnotbeallowedto
drainbackintothewaterheater.
□ Ensurethathotandcoldwaterlinesarenot
crossedtotheunitandareleakfree.
□ Cleantheinletwaterfilterbyclosingthecoldand
hotwaterinletisolaon(shut‐off)valves.Puta
bucketunderthefilterattheboomofthewater
heatertocatchanywaterthatiscontainedinside
theunit.Unscrewthewaterfilter.Rinsethe
filtertoremo
veanydebris.Installthefilterand
opentheisolaonvalves.
□ Ensurethatapressurereliefvalveisinstalledwith
arangthatexceedstheBTUinputofthewater
heatermodel.
□ Amanualgascontrolvalvehasbeenplacedinthe
gaslinetothewaterheater.
□ Checkthegaslinesandconneconsforleaks.
□ Confirmthatthegasinletpressureiswithin 
limits.
□ Confirmthatthewaterheaterisratedforthegas
typesupplied.
□ Confirmthattheelectricityis suppliedfroma120
VAC,60Hzpowersource,isinaproperly
groundedcircuit,andturnedon.
□ Verifythetemperaturecontrollerisfunconing
properly.
□ VerifythatswitchesNo.2andNo.3intheSW1
DIPswitchissetcorrectlyforyouraltude.
□ Verifythesystemisfunconingcorrectlyby
connecngyourmanometertothegaspressure
testportonthewaterheater.Operateallgas
appliancesinthehomeorfacilityathighfire.The
inletgaspressureatthewaterheatermustnot
dropbelowthatlistedontherangpla
te.
□ Ifthewaterheaterisnotneededforimmediate
use,thendrainthewaterfromtheheat
exchanger.
□ Installthefrontpanel.
□ Explaintothecustomertheimportanceofnot
blockingtheventterminaonorairintake.
□ Explaintothecustomertheoperaonofthe
waterheater,safetyguidelines,maintenance,and
warranty.
□ Theinstallaonmustconformwithlocalcodesor,
intheabsenceoflocalcodes,withtheNaonal
Fuel Gas Code, ANSI Z223.1/NFPA 54.Ifinstalled
inamanufacturedhome,theinstallaonmust
conformwiththeManufactured Home
Construcon and Safety Standard, Title 24 CFR,
Part 3280.
□ Leavetheenremanualtapedtothewater
heaterorgivetheenremanualdirectlytothe
consumer.
