Type of installation: inground (mod. J-4000 5,64 m/19 ft.)
plain view / section
~ 90 cm*
service area
~ 90 cm*
service area
sump pump
[MXL¾SEXW[MXGL
hollow concrete block with steel re-bar
and poured concrete in cavity space
gravel drain
pit access
or
service
area
~ 60 cm*
(wide crawl way)
~ 60 cm*
(wide crawl way)
564 cm*
~ 60 cm*
(wide crawl way)
236 cm* ~ 60 cm*
(wide crawl way)
* Jacuzzi can not be held liable for the accuracy of thi drawing; it is purely provided as a guide only. As each Swim Spa installation has its own set of challenges and variations due to materials
used and location of the installation.
