7. Prepare and install a new load cell following reversibly the steps 2~6.
8. Pay attention to the clearances of the overload and pull-up protectors. (Marked with 1’s
and 2’s in the third figure below.)
9. Switch on the scale and to check the offset value. Conduct calibration, then to check
weighing functions.
STEP ONE
STEP TWO
STEP THREE
