Page #9 background imageLoading...
Page #9 background image
JADEVER JCE/JWE Service Manual - V05
As per the right of proprietary intellectual property, may not be reproduced in any form without written permission.
8
CHAPTER 2 SET UP
2-1 Models
On the A/D PCB, jumpers TPI and TP2 are used to determine the capacity model, as shown
below: (Do know that in different capacity model, load cell used may be different.)
Capacity TP1 TP2
3kg Shorted Shorted
6kg Open-circuited Shorted
15kg Shorted Open-circuited
30kg Open-circuited Open-circuited
2-2 Calibration
Note: Metrological controls and/or regulations
The regulations and/or metrological controls governing to conduct
calibration vary from country to country.
Please do follow the local metrological controls and/or regulations
imposed by the local authority.
On the A/D PCB, jumper CAL and jumper TC are used to determine the ON/OFF of the
calibration function and TC (temperature compensation), respectively, as shown below:
Jumper Calibration/TC ON Calibration/TC OFF
CAL
open Shorted
TC
shorted open
