Jamestown J2000T - Framing Instructions for Fireplace Inserts; Chase Frame Opening Sizes

Page 23
1998-2006 Edition
Parts List 1. Exhaust Stub 2. Air Intake Stub 3. Air Intake Adapter Extension Mounting Holes 4. Air Intake Adapter Extension 5. 45º Elbow Housing 6. 3” (76mm) Diameter 45º Elbow 7. 19” (483mm) long 3” (76mm) Diameter Exhaust Pipe 8. Air Intake Adapter Housing with 4-3/4” (121mm) Pipe 9. Wall Thimble Inner Piece (Painted Face) 10. Wall Thimble Outer Piece 11. 4-3/4” (121mm) End Cap/Rodent Screen 12. 3” (76mm) Rain Cap with Rodent Screen
