CONTROL BOARD PROGRAM PARAMETERS TABLES
Page 58
1998-2006 Edition
The control board uses the parameters in the following tables from the Row # that corresponds to the
selector switch position. The tables below list the various parameters specific to each model. When
changing the program, please refer to the table that is specific to the model of stove you purchased.
TABLE X1: J1OOOB PROGRAM PARAMETERS
Program
selector
switch #
Mode High Fuel
ON Time
(Sec)
High
Fuel
OFF
Time
(Sec)
Low Fuel
ON Time
(Sec)
Low Fuel
OFF
Time
(Sec)
Convection
Blower Low
Limit
Voltage
(Volts AC)
Convection
Blower High
Limit Voltage
(Volts AC)
STARTUP
CYCLE
TOTAL LENGTH
(Min)
STARTUP
CYCLE
Heater ON Time
(Min)
STARTUP
CYCLE
Fuel ON Time
(Sec)
STARTUP
CYCLE
Fuel OFF Time
(Sec)
0 Auto 6 4 2.5 7.5 100 120 12 5 3 7
1 Auto 6 4 2.5 7.5 105 120 12 5 3 7
2 Auto 6 4 2.5 7.5 100 120 12 5 3.5 6.5
3 Auto 6 4 3 7 105 120 12 5 3.5 6.5
4 Auto 5.5 4.5 3 7 105 120 12 5 3 7
5 Semi 6 4 2.5 7.5 100 120 12 5 3 7
7 Semi 6 4 2.5 7.5 105 120 12 5 3 7
8 Semi 6 4 2.5 7.5 100 120 12 5 3.5 6.5
8 Semi 6 4 3 7 105 120 12 5 3.5 6.5
9 Semi 5.5 4.5 3 7 105 120 12 5 3 7
TABLE X2: J2000T and J2001T PROGRAM PARAMETERS
Program
selector
switch #
Mode High Fuel
ON
Time (Sec)
High Fuel
OFF Time
(Sec)
Low Fuel
ON
Time
(Sec)
Low Fuel
OFF Time
(Sec)
Convection
Blower Low
Limit Voltage
(Volts AC)
Convection
Blower High
Limit Voltage
(Volts AC)
STARTUP
CYCLE
TOTAL
LENGTH (Min)
STARTUP
CYCLE
Heater
ON Time (Min)
STARTUP
CYCLE Fuel
ON Time
(Sec)
STARTUP
CYCLE
Fuel OFF Time
(Sec)
0 Auto 7.5 2.5 25 7.5 100 120 12 5 3 7
1 Auto 7.5 2.5 2.5 7.5 105 120 12 5 3 7
2 Auto 7.5 2.5 2.5 7.5 100 120 12 5 3.5 6.5
3 Auto 7.5 2.5 3 7 105 120 12 5 3.5 6.5
4 Auto 6.7 3.3 3 7 105 120 12 5 3 7
5 Semi 7.5 2.5 2.5 7.5 100 120 12 5 3 7
6 Semi 7.5 2.5 2.5 7.5 105 120 12 5 3 7
7 Semi 7.5 2.5 2.5 7.5 100 120 12 5 3.5 6.5
8 Semi 7.5 2.5 3 7 105 120 12 5 3.5 6.5
9 Semi 6.7 3.3 3 7 105 120 12 5 3 7
