Page ii
1998-2006 Edition
JAMESTOWN PELLET STOVES SPECIFICATIONS iv
STOVE EXTERIOR PARTS IDENTIFICATION DIAGRAMS
J1000B and J2000T v
J20001T vi
CHAPTER I: SAFETY FIRST, ALWAYS! 1
Caution 1
Safety Notices 2
CHAPTER II: INSTALLATION REQUIREMENTS 3
General Requirements 3
Manufactured (Mobile) Home Installation Requirements 4
CHAPTER III: CLEARANCES TO COMBUSTIBLES REQUIREMENTS FOR J1000B & J2000T 5
Floor Protection Requirement 5
Installing On Carpet Or Other Combustible Floor 5
Alcove Installation 6
Corner Installation 6
Vertical Clearances 7
Clearances for Insert 8
CHAPTER IV: CLEARANCES TO COMBUSTIBLES REQUIREMENTS FOR J2001T INSERT 9
Installation in a Pre-Manufactured Wood Burning Fireplace 9
Installation in Wood Framed Enclosure/Chase 9
Floor Protection Pad Requirement for All Installations 9
Clearances to Combustibles Requirement Diagrams 10
CHAPTER V: GENERAL VENT SYSTEM INFORMATION 11
Warning 11
Using an Existing Chimney to Vent a Pellet Stove 11
Installations Requiring a Complete New Chimney System 11
CHAPTER VI: VENT SYSTEM CONFIGURATION OPTIONS 13
Coaxial Direct Through-the-Wall Horizontal Vent Termination - J3020A 13
J3020A Kit Installation Instructions 14
Conventional Direct Through-the-Wall Horizontal Vent Termination 18
Coaxial Through-the-Wall 45° Horizontal Vent Termination 20
Conventional Through-the-Wall 45° Horizontal Termination 24
Vertical Venting Using an Existing Chimney 25
Vertical Venting Outside Roof Line - Unit Back Parallel to Outside Wall 26
Vertical Venting Inside Roof Line - Unit Back Parallel to Outside Wall 27
CHAPTER VII: INSTRUCTIONS FOR FRAMING THE J2001T OR J1001B FIREPLACE INSERT 29
Inside The Room and Recessed in an Interior Chase 30
Recessed in an Exterior Chase 30
Corner Installation 31
Vertical Venting 32
TABLE OF CONTENTS
