Page iv
1998-2006 Edition
JAMESTOWN PELLET STOVES SPECIFICATIONS
J1000B
Without Leg,
Pedestal Or Riser
J2000T
With Standard
Pedestal
J2001T
Without Riser
Standard Color METALLIC
CHARCOAL
METALLIC
CHARCOAL
METALLIC
CHARCOAL
Maximum BTU Input 34,000 42,000 42,000
Vent Pipe Diameter 3" (76 mm) or
4" (101 mm)
3" (76 mm) or
4" (101 mm)
3" (76 mm) or
4" (101 mm)
Electrical Ampere Rating with Auto Ignition
(without Auto Ignition)
5.2
(2.2)
7.5
(2.5)
7.5
(2.5)
Vent Pipe Type TYPE L TYPE L TYPE L or SS Flex
Height [in./mm.] 24/610 30/762 22.5/572
Width [in./mm.] 23/584 26/660 26/660
Depth [in./mm.] 13.5/343 24.5/622 24.5/622
Weight (lb./ kg.) 175/80 220/100 220/100
Shroud Size ( Width" X Height")
Standard
Large
29" X 42"
35" X 50"
NA
NA
29" X 41.5"
35" X 49.5"
Fuel Hopper Capacity (Lb./Kg.) 37/16.8 58/26.4 58/26.4
Minimum Fireplace Depth (in./ mm.) NA NA 16.5/419
Minimum Fireplace Rear Width (in./ mm.) NA NA 26/660
Minimum Fireplace Rear Height (in./ mm.) NA NA 22.5/572
Maximum Vertical Vent Length (Ft./M.) 35/10.5 35/10.5 35/10.5
Maximum Horizontal Vent Length (Ft./M.) 25/7.5 25/7.5 25/7.5
CLEARANCES TO COMBUSTIBLES REQUIREMENTS
J1000B J2000T J2001T
Stove Back To Back Wall (in./mm.) 1/25 1/25 1/25
Stove Side Panel To Standard Side Wall
(in./mm.)
3/76 3/76 3/76
Stove Side Panel To Alcove Side Wall (in./mm.) 5/127 5/127 5/127
Stove Rear Corners To Standard Side Wall
(in./mm.)
1/25 1/25 1/25
Stove Rear Corners To Alcove Side Wall
(in./mm.)
5/127 5/127 5/127
Stove Front To Carpet Or Any Combustible
Floor (in./mm.)
6/152 6/152 6/152
Manufacturer reserves the right to change all or some of the specifications without prior written notice.
