Jandy
®
Pro Series, CS Single Element Cartridge Pool & Spa Filter
|
Installation & Operation Manual
18 1/2”
3 1/4”
A
14 3/4”
Figure 7. Dimensions, CS Cartridge Series Filter
Figure 8. Dimensions, CS Cartridge Series Filter -
Top View
Outlet Port
Inlet Port
Drain
Port
13”
20 1/8”
14 1/8”
10.3 Dimensions
Dimension “A”:
• CS100 - 32 ⅜”
• CS150 - 32 ⅜”
• CS200 - 42 ½”
• CS250 - 42 ½”

Jandy CS200 Specifications

General

Brand	Jandy
Model	CS200
Category	Water Filtration Systems
Language	English
