ENGLISH
Jandy
®
Pro Series, CS Single Element Cartridge Pool & Spa Filter
|
Installation & Operation Manual
Section 2. General Information
2.1 Introduction
This manual contains information for the proper
installation and operation of the Jandy Pro Series CS
Cartridge Filters. Procedures in this manual must be
followed exactly. For technical assistance, contact our
Technical Support Department at 1.800.822.7933.
2.2 Description
Cartridge lters do not require sand or diatomaceous earth
as the lter medium. Instead they contain a lter cartridge
element which is easily removed for cleaning or replacement.
Dirty water ows into the lter tank and is directed
through the lter cartridge. The debris is collected on the
surface of the cartridge as the water ows through it. The
water will travel through the central lter core towards
the bottom of the lter into the lower manifold. Clean
water is returned to the swimming pool through the lter
outlet port at the tank's bottom.
As debris collects in the lter, the pressure will rise and
water ow to the pool will diminish. The lter cartridge
must be cleaned when the operating pressure of the
lter rises 10 psi from the operating pressure of a clean
cartridge. See Section 6 "Cleaning the Filter".
NOTE A filter removes dirt and other suspended particles
but does not sanitize the pool. Pool water must be
sanitized and chemically balanced for clear water.
The filtration system should be designed to meet
local health codes. At a minimum, the system should
turnover the total volume of water in your pool two (2)
to four (4) times in a 24 hour period.
2.3 General Requirements
1. For best overall performance place the system as
close to the pool as possible.
2. The lter should be located on a level concrete
slab so that the orientation of the valve outlets and
the pressure gauge are convenient and accessible
for the installation and operation of the unit.
3. Protect the lter from the weather.
4. If tting a chlorinator and/or any other device into
the ltration plumbing circuit, great care must be
exercised to ensure that the appliance is installed
in accordance with the Manufacturer’s Instructions
and any applicable standards that may exist.
5. Use Jandy Pro Series universal unions to connect
each component of the water conditioning system
for future servicing. All Jandy Pro Series lters
come with these type of ttings.
WARNING
The maximum operating pressure for this filter is 50
psi. Never subject the filter to operating pressure
exceeding 50 psi. Operating pressures above 50 psi
can cause product failure or also cause the lid to be
blown off, which can result in death, serious personal
injury, or property damage.
6. When performing hydrostatic pressure tests or
when testing for external leaks of the completed
ltration and plumbing system, ensure that
the maximum pressure the ltration system is
subjected to does not exceed the maximum
working pressure of any of the components
within the system.
Section 3.
Installation Instructions
WARNING
Use equipment only in a pool or spa installation. Do not
connect system to an unregulated city water system or
other external source of pressurized water producing
pressures greater than 35 psi.
3.1 Filter Location
WARNING
To Reduce the Risk of Fire, install pool equipment in
an area where leaves or other debris will not collect
on or around the equipment. Keep surrounding area
clear of all debris such as paper, leaves, pine-needles
and other combustible materials.
1. Select a well-drained area, one that does not ood
when it rains. Damp, non-ventilated areas should
be avoided.
2. The lter should be installed on a rm, solid, and level
surface or platform to avoid risk of settlement. Do not
use sand to level the lter as the sand will wash away;
lter systems can weight up to 300pounds. Check
local building codes for additional requirements.
(Ex. Equipment pads in Florida must concrete and
equipment must be secured to the pad.)
3. Install electrical controls at least ve (5) feet from
the lter. This will allow enough room to stand away
from the lter during start-up.
4.
Allow sufcient clearance around the lter to permit
a visual inspection of the clamp ring. See Fig. 1.
