Section 3. Installing the Jandy Pro Series
Nicheless LED Light
WARNING
Risk of Electrical Shock or Electrocution.
This underwater light
must be installed by a licensed or certified electrician or a qualified pool
serviceman in accordance with the National Electrical Code
®
(Canadian
Electrical Code, in Canada) and all applicable local codes and
ordinances. Improper installation will create an electrical hazard, which
could result in death or serious injury to pool or spa users, installers or
others due to electrical shock, and may also cause damage to property.
Always disconnect the power to the light at the circuit breaker before
installing or servicing the light. Failure to do so could result in death or
serious injury to serviceman, pool or spa users or others due to electrical
shock.
NOTE: Jandy Pro Series Nicheless Lights are Low Voltage and do not
have any exposed metal and as such do not require a separate ground or
bonding wire.
3.1 Preparing the Light Fixture for Installation
NOTE: The electrician must complete preparatory steps before light xture
is installed. See Figure 1.
Verify that the pool meets the requirements of the current National Electri-
cal Code
®
(Canadian Electrical Code, in Canada) and all local codes and
ordinances. A licensed or certied electrician must install the electrical
system to meet or exceed those requirements before the underwater light is
installed. Some of the requirements of the National Electrical Code, which
the pool electrical systems must meet, are as follows:
1. The junction box or the low-voltage magnetic transformer must be
located at least eight (8) inches (measured from the inside of the
bottom of the junction box or transformer) above the MAXIMUM
water level, OR at least four (4) inches above the ground level or pool
deck, whichever is greater. The junction box or 12VAC magnetic
transformer must also be installed at least forty-eight (48) inches (4 ft.)
from the edge of the pool. See Figure 1.
2. 1.5” pipe must be installed through the bond beam followed by 1”
conduit for the cord using sweep elbows only for turns. Do not use 90
degree elbows. It is highly recommended to use 1.5” pipe throughout
the entire width of the bond beam, however, the minimum length for
the particular light being installed is specied in Table 1.
