ENGLISH
Page 9
4.2 Wire Gauge and Length
CAUTION
Jandy
®
Pro Series Nicheless Underwater LED Lights are low voltage
fixtures. Improper wire gauge and wire length can effect the performance
of these products. Follow the guidelines below to determine the proper
operation and optimum performance of the lights.
Voltages are determined by the measured voltage level at the Bus Bar where
the transformer and cords are connected.
NOTE: Each color mode has a slightly different power draw
6W & 12W lights: Min/Max Voltage per cord length
Cord Length Min. Voltage Max. Voltage
50 Feet 9.4VAC 12.4VAC
100 Feet 10.7VAC 13.2VAC
150 Feet 11.82VAC 13.8VAC
24W Lights: Min/Max Voltage per cord length
Cord Length Min. Voltage Max. Voltage
50 Feet 10.34VAC 12.56VAC
100 Feet 10.9VAC 13.5VAC
150 Feet 11.43VAC 14.1VAC
Table 2. Jandy
®
Pro Series LED Light Voltage Min/Max Levels
WARNING
RISK OF ELECTRICAL SHOCK OR ELECTROCUTION,
which could result in serious injury or death.
A Ground Fault
Circuit Interrupter (GFCI) for 120 Volt transformers should be used if
required by the transformer manufacturer or if required by the local
applicable code and/or Authority Having Jurisdiction (AHJ). When
a GFCI is used, the conductors on the load side of the GFCI circuit
shall not occupy conduit, boxes, or enclosures containing other
conductors unless the additional conductors are also protected by a
GFCI. Refer to local codes for complete details.
