Section 6 Manual operation (initial operation, maintenance, service)
Programming of fixed stages
In manual operation, capacitor branches can be connected/disconnected in the set
control series and switching time - irrespective of prevailing power-line conditions.
Manual operation 1: The starting condition is STOPP (no stages connected).
Connections are made by pressing the é key (CAP ON).
Pressing ê initially leads back to STOPP mode.
Repeated pressing of ê leads to the disconnection of stages (CAP OFF).
The active operating status and active power factor are always shown on the display.
Pressing ENTER takes the user to the Manual operation 2.
Normally, all stages are programmed for automatic operation (default setting).
Here all controller outputs (C1 - C12) may be permanently defined in succession
(continued switching via ENTER) for the following statuses:
FIXED: The output is continuously connected, e.g. for fixed PFC. The output is
marked by an underlined capacitor symbol.
AUTO: Automatic (normal) operation
The relevant output is marked by a capacitor symbol.
OFF: The output is continuously disconnected - e.g. for temporarily disconnecting a
defective capacitor. The capacitor symbol for this output is faded out. Minus ( - )
appears.
ON: The selected stage will be switched ON (maybe putting into operation)- in case
a discharge-time is active - it will be shown at the display
The active stage is blinking. The required status is set via é /ê. By pressing ENTER, the
user saves this step and moves to the next stage.
The programmed statuses for the outputs also remain visible on the display in automatic
operation.
After the required settings have been made, pressing the "Operating Mode” key takes the
user to the next menu ("Service”) or further to "Automatic Operation”.
- 14 -
MANUAL MODE 1
------------------
MANUAL MODE 1
------------------
MANUAL MODE 1
------------------
STOP 1.000 CAP ON 0.871 CAP CAP OFF 0.871 CAP
1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12
device-Stop connection of steps disconnection of steps
MANUAL MODE 2
------------------
MANUAL MODE 2
------------------
MANUAL MODE 2
------------------
C1 - [AUTO] C1 - [ FIXED] C1 - [ON] 20 s
1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11 12
