Prophi
®
12R / 12 RS
33
Operating diagram (Brief programming)
Power Factor Controller Prophi 12RS
MANUAL MODE SERVICE EXPERT.MODE 1
STOPP C 1.00 IND
MANUAL MODE 1
MANUAL MODE 2
1 min/max VOLTAGE
0 / 250.0 V
1 PASSWORD ????
[ 6343 ]
2 max REACTIVE POWER
88.88 kvar
5 INTEGRATION
TIME [ 1 ] s
3 max ACTIVE POWER
88.88 kW
4 max APPARENT POWER
88.88 kVA
5 max TEMPERATURE
40.0 °C
6 max THD V/I
V 2.7 % - I 1.0 %
7 MAXIMUM VALUES
RESET [ NO ]
10 ERROR MEMORY
Plain text...
12 START TEST RUN
[ NO ]
15 - 27 SERVICE TELEFON
TEL.: [ ... ]
2 BASIC SETTINGS
NEW ? [ NO ]
3 SWITCH.OPERATION
RESET [ NO ]
4 OPERATING TIME
RESET [ NO ]
C1 : AUTO (FIXED / OFF )
C2 : AUTO (FIXED / OFF )
C3 : AUTO (FIXED / OFF )
C4 : AUTO (FIXED / OFF )
C5 : AUTO (FIXED / OFF )
C6 : AUTO (FIXED / OFF )
C7 : AUTO (FIXED / OFF )
C8 : AUTO (FIXED / OFF )
C9 : AUTO (FIXED / OFF )
C10 : AUTO (FIXED / OFF )
C11 : AUTO (FIXED / OFF )
C12 : AUTO (FIXED / OFF )
8 SWITCHING OPER.
C [ 1 ] - 123
11 ERROR MEMORY
RESET [ NO ]
14 SERVICE INTERVAL
[ -- ]
13 C - POWER
C[1] = 23 kvar MEAS
C[1] = 25 kvar NOM.
9 OPERATION TIME
C [ 1 ] - 12h
6 SWITCH. POWER
max [100] kvar
7 SWITCH. TRIGGER
IND [ 66 ] %
8 SWITCH. TRIGGER
CAP [ 66 ] %
9 PROGRAM LOCK
[ NO ]
10 SWITCH. OPERATION
WARNING [50 000]
11 FAST DISCHARGE
[ NO ]
12 FAST DISCHARGE TIME
[ 10 ] s
13 PHASE I
[ L1 ]
14 PHASE V 0°
[ L1- N ] I: L1
15 C - TEST
[ YES ]
16 C - FAILURE
- [ 50 ] %
16 C - FAILURE
+ [ 150 ] %
17
[ 6 ]
TEST ATTEMPT
18 OUTPUT 1.STEP
[ 0 ... 255 kvar ]
19 CONTROL
[ 3 ] PHASE - CAP
20 SUPPLY [ 1 ]
[ ----- ]
21 DISPLAY
[ cos ]
22 CHANGE PASSWORD
[ NO]
27 ERROR - BACKLIGHT
[ PINK ]
28 CT - OFFSET
[ 0 ]
BACK TO 1
BACK TO 1
- 32 -
j
CONTROL SERIES EDITOR
KVAR-RATIO C1 [ 1 ]
1 2 2 2 2 2 2 2 2 2 21
KVAR-RATIO C2 [ 1 ]
1 2 2 2 2 2 2 2 2 2 21
KVAR-RATIO C3 [ 2 ]
1 2 2 2 2 2 2 2 2 2 21
KVAR-RATIO C4 [ 2 ]
1 2 2 2 2 2 2 2 2 2 21
KVAR-RATIO C12 [ 2 ]
1 2 2 2 2 2 2 2 2 2 21
BACK TO 1
up to capacitor 12
only available if control
serie “E” is selected
To Next Page
