The controller is supplied as standard for an operating voltage of 110...440 VAC (+-10%),
a measuring voltage of 30...440 V~ (L-N) resp. 50...760V~(L-L) and a measuring current
of 5A or 1A. A voltage converter is required for different operating voltages.
Caution!
Voltages which exceed the specified voltage range can damage the
device !
- 4 -
!
Operating mode:
- Automatic
- Program.
- Manual oper.
- Service
- Expert Mode
- Osci - Mode
- Display Editor
ENTER/ OK
Confirmation
storage of
values
Increase
selected
parameter
HELP
opens
Help pages
Reduce
selected
parameter
Escape
previous
page/value
in the display
Front view
Rear view
H
H
E
E
L
L
P
P
E
E
S
S
C
C
Alarm relay
Power Factor Controller
1 2
EXT. IN-/OUTPUT
ON INTERFACE RS 485
SERVICE
Gnd B A PE
ext. Input
110...230V
message-
relay
terminating-
resistor
capacitor contactors 1 - 6 capacitor contactors 7 - 12
P1 P21 72 83 94 105 116 12
MADE IN GERMANY
RJ45
Art.no.:
Ser.no.:
50 - 760 V~ (L-L)
Meas.voltage: 30 - 440 V~ (L-N)
Supply volt.: 110...440VAC 50/60Hz
L N L1 N k l
(L3) (L2)
a b
supply volt. meas.voltage meas.current
