Measuring method
The UMG 96RM-EL measures uninterrupted and
calculates all root mean squares over a 10/12-period
interval (200ms). The UMG 96RM-EL measures the true
root mean square (TRMS) of the voltages and currents
applied to the measuring inputs.
Operating concept
There are several ways to program the UMG 96RM-EL
and retrieve measured values.
• Directly on the device using two buttons.
• Via the programming software of the GridVis.
These operating instructions only describe the operation
of the UMG 96RM-EL using the 2 buttons.
The programming software of the GridVis has its own
“online help”.
GridVis network analysis software
The UMG 96RM-EL can be programmed and read with
the GridVis network analysis software which is part of the
scope of delivery. For this a PC must be connected to
the UMG 96RM-EL via Ethernet.
Characteristics of GridVis
• Programming the UMG 96RM-EL
• Graphic representation of measured values
