Page #9 background imageLoading...
Page #9 background image
9
UMG 96RM-EL
Performance characteristics - UMG 96RM-EL
General
Front panel integration device with dimensions
96x96 mm.
Connection via pluggable screw terminals
LCD display with backlighting
Operation via 2 buttons
3 voltage measurements inputs (300V CATIII)
3 current measurement inputs for
current transformer.
Ethernet interface
Working temperature range -10°C .. +55°C
Storage of minimum and maximum values
(without time stamp).
Uncertainty in measurement
Active energy uncertainty in measurement class
0.5 for ../5A transformer
Active energy uncertainty in measurement class 1
for ../1A transformer
Reactive energy, class 2
Measurement
Measurement in IT, TN and TT networks
Measurement in networks with nominal voltage
up to L-L 480V and L-N 277V
Measuring range current 0 to 5A eff.
True RMS (TRMS)
Continuous sampling of the voltage and current
measurement inputs
Frequency range of the mains frequency
45 Hz .. 65 Hz.
Measurement of harmonics 1 to 40
for ULN and I.
Uln, I, P (import/delivery), Q (ind./cap.).
Fourier analyses 1 to 40. Harmonic for U and I.
7 Energiezähler für
Active energy (import)
Active energy (export)
Active energy (without a backstop)
Reactive energy (ind.)
Reactive energy (capacitive)
Reactive energy (without a backstop)
Apparent energy
each for L1, L2, L3 and total.
