UMG 96RM-PN

Device parameters

• Supply voltage:

Option 230V: 90V - 277V (50/60Hz) or

DC 90V - 250V; 300V CATIII

Option 24V: 24 - 90V AC / DC; 150V CATIII

• Frequency range: 45 - 65 Hz

Device functions

• 3 voltage measurement channels, 300V

• 4 current measurements

(via current transformer ../5A or ../1A)

• 2 residual current measurements

(via residual current transformer ../30mA) or

optionally 2 temperature measurements

• RS485 interface, ethernet and ProﬁNet

• 2 digital outputs and additionally 3 digital inputs/

outputs

Connection Example2
- Table of Contents2
Table of Contents4
General Information4
Inspection on Receipt6
- Available Accessories7
Product Description8
- Proper Use8
- UMG 96RM-PN Features10
- Measuring Process11
- Operating Concept11
- Gridvis Network Analysis Software11
- Connection Variants12
Assembly13
Installation15
- Supply Voltage15
- Voltage Measurement16
- Current Measurement Using I1 to I422
- Analogue Inputs30
- Residual Current Monitoring (RCM) Via I5, I631
- Thermistor Input33
- RS485 Interface34
- Ethernet / Profinet Interface37
- Digital In-/Outputs39
- LED Status Bar44
Operation45
- Display Mode45
- Programming Mode45
- Parameters and Measured Values47
Configuration49
- Connecting the Supply Voltage49
- Current and Voltage Transformer49
- Programming the Current Transformer for I1-I351
- Programming the Voltage Transformer52
- Programming Parameters53
- TCP/IP Configuration54
- RS485 Device Address (Addr. 000)56
- RS485 Baud Rate (Addr. 001)56
- User Password (Addr. 050)57
Parameters58
- Mean Value58
- Averaging Method58
- Min. and Max. Values58
- Mains Frequency (Addr. 034)59
- Power Meters60
- Resetting Energy Meters (Addr. 507)60
- Harmonics61
- Measured Value Rotation62
- Measured Value Screens62
- Direction of the Rotating Field64
- LCD Contrast (Addr. 035)64
- Backlight64
- Time Logging66
- Operating Hours Counter66
- Total Running Time, Comparator66
- Serial Number (Addr. 754)67
- Software Release (Addr. 750)67
Commissioning68
- Connecting the Supply Voltage68
- Connecting the Measured Voltage68
- Applying the Measuring-Circuit Voltage68
- Direction of the Rotating Field69
- Checking the Phase Assignment69
- Checking the Power Measurement69
- Applying the Residual Current69
- Failure Monitoring (RCM) for I5, I670
- Checking the Measurement71
- Checking the Single Phase Powers71
- Checking the Sum Powers71
RS485 Interface72
Digital Outputs74
- Digital Output Status Indicators75
- Pulse Output (Group 1)77
- Comparators and Threshold Value Monitoring82
Service and Maintenance88
- Service88
- Device Calibration88
- Calibration Intervals88
- Firmware Update89
Error / Warning Messages90
Technical Data96
- Function Parameters103
- Table 1 - Parameter List105
- Table 2 - Modbus Address List112
- Number Formats115
- Dimension Diagrams116
Measured Value Screen Overview118
Connection Example 1124
- Connection Example 2125
Basic Functions Quick Guide126
TCP/IP Addressing Quick Guide127
