Page 29= Peak value = Minimum value = Supply
Configuration data
Description Display Setting range Presettings
Current transformer, primary CT 1A .. 10,0kA (../5A) 5A
1A .. 2,0kA (../1A)
Current transformer, secondary CT 1A, 5A 5A
Voltage transformer, primary
Type plate, 196 .. 275V VT 100V .. 60,0kV 400V
Typeplate, 98 .. 140V VT 100V .. 60,0kV 200V
Type plate, 49 .. 76V VT 100V .. 60,0kV 100V
Current transformer secondary
Type plate, 196 .. 275V VT 400V (cannot be changed) 400V
Type plate, 98 .. 140V VT 200V, 220V 200V
Type plate, 49 .. 76V VT 100V, 110V 100V
Outputs (by choice) Kx
Pulse output K1, K2 K1, K2
Measured values Reactive and real energy K1=Real., K2=React.
Pulse valency 0,00(W/var)h .. 99,9k(W/var)h K1=1,00Wh, K2=1,00varh
Switching output K1, K2 -
Measured value All values except energy -
Exceeding 0,01 .. 20,0M -
Underscoring 0,01 .. 20,0M -
Minimum pulse width 0.05...2.00 sec. 0.05 sec.
Averaging time current 5, 10, .. 900 sec. 900 sec.
Averaging time power 5, 10, .. 900 sec. 900 sec.
Rotation time 0 .. 255 0=no rotation
Measured value rotation see table No measured value rotation
Measured value selection see table All measured value indicat.
LCD contrast 0 .. 15 7
Software Release x.xx x.xx
User password 000 .. 999 „000“ = no password
These specifications presuppose a yearly calibration and a warm up time of 10 minutes.
Used abbreviations:
rng = of measuring range
rdg = of measured value
