Page 30 = Peak value = Minimum value = Supply
Technical data
Wei gh t : 250g
Calorific value : 2,2MJ (610Wh)
Ambient conditions
Overvoltage class : CATIII
Pollution degree : 2
Ambient temperature : -10°C .. +55°C
Storage temperature : -20°C .. +70°C
Humidity : 15% up to 95% without dew
Protection class
Front : IP40 according to IEC529
Front with seal (option) : IP42 according to IEC529
Back side : IP20 according to IEC529
Protection class : II = without protective wire
Installation place : any
Height : 0 .. 2000m over NN
Resistance against interf. (Industr. areas) : EN50082-2:1995; IEC1000-4-,3, 10V/m
: IEC1000-4-4, 2kV; IEC1000-4-2, 8kV
Interference radiation (residential areas) : EN55011 10.1997
Safety guidelines : EN61010-1 03.1994 + A2 05.1996; IEC1010-1
Measurement
Measurement and supply voltage : see type plate
Measuring inputs
Scanning frequency : 1 Measurement/sec.
Rated pulse voltage : 4kV
Signal frequency : 45Hz .. 65Hz
Current measurement : max. 300VAC against earth
Power consumption : about 0,2 VA
Rated current at ../5A (../1A) : 5A (1A)
Min. energying current : 20mA
Current limit at ../1A : 1,2A (sinus shape)
Current limit at ../5A : 6A (sinus shape)
Overload : 180A for 2 Sek.
Voltage measurement : max. 300VAC against earth
Power consumption
196 .. 275V (see type plate) : max. 13,4VA / Phase
98 .. 140V (see type plate) : max. 7,4VA / Phase
49 .. 76V (see type plate) : max. 2,6VA / Phase
Fuse : 2A..6A (medium time-lag type)
Frequency of fundamental : 45Hz .. 65Hz
Outputs
Type : NPN-Transistor
Switching frequency : max. 10Hz (50ms pulse width)
Operating current : max. 50 mA (not short-circuit-proof)
Permissible rest current : < 1mA
Operating voltage : 5.. 24VDC, max. 30VDC
Connectable cables
One wire, multiple-wire, fine wire : 0,08 - 2,5mm
2
Pin contacts : 1,5mm
2
Only one wire may be connected at one clamp!
