UMG 96RM-P/-CBM
Current measuring I4
Measurement range 0 .. 5A
rms
(max. overload 7 Arms )
Crest factor 1,98
Resolution 0.1mA (Display 0.01A)
Accuracy class 1 (IEC61557-12)
Overvoltage category 300V CAT II
Measurement surge voltage 2kV
Power consumption Approx. 0.2 VA (Ri=5mOhm)
Overload for 1 sec. 120A (sinusoidal)
Sampling frequency
21.33kHz (50Hz); 25.6 kHz (60Hz) per measurement channel
Connection characteristics of the terminal I4 (current measurement)
Conductors to be connected. Only one conductor can be connected per terminal!
Single core, multi-core, fine-stranded 0.2 - 2.5mm
2
, AWG 24-12
Terminal pins, core end sheath 0.25 - 2.5mm
2
Tightening torque 0.5 - 0.6Nm
Stripping length 7mm
