44
UMG 96RM-P/-CBM
Dimension diagrams
Cut-out size: 92
+0,8
x 92
+0,8
mm.
Rear view of UMG 96RM-P
Side view of UMG 96RM-P
with USB and Profibus connectors inserted
57
6
96
100
ca. 108
91
65
78
(depth without connector)
All dimensions in mm
43
45
Table of Contents
Table of Contents
2
General
3
Incoming Inspection
6
Expanded Scope of Delivery UMG 96RM-P or -CBM
7
Available Accessories
7
Product Description
8
Proper Use
8
Expanded Features of the UMG 96RM Variants P and CBM
9
Measuring Process
10
Gridvis Network Analysis Software
12
Connection Variants
12
Use of the Device
13
LED Status Bar
14
Current Transformer Input I4
16
USB Interface
18
Installation of USB Driver
20
Digital Outputs
22
DC Connection Example
23
Digital Inputs
24
Profibus Interface (Only UMG 96RM-P)
26
Service and Maintenance
34
Battery
34
Battery Monitoring Function
35
Replacing the Battery
36
Firmware Update
37
Device Calibration
37
Calibration Intervals
37
Procedure in the Event of Faults
38
Technical Data for the Expansions
40
Declaration of Conformity
46
Connection Example
48
