janitza UMG 96S User Manual

Page 43
Indication profile (Addr. 604)
The specific profile No. 3 can be configured by
the PC software GridVis only, but not directly at
UMG96S. For this profile, a connection between
UMG96S and PC via serial interface (RS232 or
RS485) is mandatory.
Format of the indication profile:
STRING
Byte 1 = row 1,
Bit1 = 1. measured value table,
Bit2 = 2. measured value table,
...
Bit8 = 8. measured value table.
Byte 2 = row 2,
Bit1 = 1. measured value table,
Bit2 = 2. measured value table,
...
Bit8 = 8. measured value table
....
Byte 32 = row 32,
Bit1 = 1.measured value table,
Bit2 = 2. measured value table,
....
Bit8 = 8. measured value table.
Indication profile No.2
(See page 86 to 89)
ABCDEFGH
01 x x x
02 x x x
03 x x x x
04 x x x x
05 x x x
06 x x x x
07 x x x
08 x x x
09 x x x
10 x x x
11 x x x
12 x x x
13 x x x
14 x x x
15 x
16 x x
17 x
18 x x x x
19 x x x
20 x x x x x x x x
21 x x x x x x x x x
22 x x x x x x x x x
23 x x x x x x x x x
24 x x x x x x x x x
25 x x x x x x x x x
26 x x x x x x x x x
27 x x x x x x x x x
28 x x x x x x x x x
29 x x x x x x x x x
30 x x x x x x x x x
31 x x x x x x x x x
32 x x x x x x x x x
