janitza UMG 96S User Manual

Page 77
Addr. Description Setting range Type Unit Presetting
000 UMG96S Device address 1 .. 255 CHAR - 1
001 Baud rate (RS232 and RS485) 0 .. 2 CHAR
1)
kbps 0
002 Input/Output 1, Type 0 .. 6 CHAR
2a)
-0
003 Input/Output 2, Type 0 .. 6 CHAR
2b)
-0
004 Pulse valence, Digital output 1 0 .. 100000 PULS Wh 1,00
5)
006 Pulse valence, Digital output 2 0 .. 100000 PULS varh 1,00
5
)
008 Delete min. and max. values 0 .. 1 CHAR - 0
009 Delete energy 0 .. 1 CHAR - 0
010 Min. pulse duration, Digital output 1/2 5 .. 99 CHAR
3)
ms 5=50ms
011 User password 0 .. 999 INT - 000
012 LCD contrast 0 .. 7 CHAR - 3
013 Comparator 1A, limit -999999999 ..
999999999 LONG 0
015 Comparator 1A, measured value 0 .. 999 INT
6)
000
016 Comparator 1A, Min. on time 1 .. 899 INT Sec. 1
017 Comparator 1A, Operator 0, 1 CHAR
4)
0
018 Comparator 1B, limit -999999999 ..
999999999 LONG
020 Comparator 1B, measured value 0 .. 999 INT
6)
021 Comparator 1B, min. on time 1 .. 899 INT Sec. 1
022 Comparator 1B, Operator 0, 1 CHAR
4)
0
023 Comparator 1C, limit -999999999 ..
999999999 LONG
025 Comparator 1C, measured value 0 .. 999 INT
6)
026 Comparator 1C, min. on time 1 .. 899 INT Sec. 1
027 Comparator 1C, Operator 0, 1 CHAR
4)
0
028 Comparator 2A, limit -999999999 ..
999999999 LONG
030 Comparator 2A, measured value 0 .. 999 INT
6)
031 Comparator 2A, min. on time 1 .. 899 INT Sec. 1
032 Comparator 2A, Operator 0, 1 CHAR
4)
0
033 Comparator 2B, limit -999999999 ..
999999999 LONG
035 Comparator 2B, measured value 0 .. 999 INT
6)
036 Comparator 2B, min. on time 1 .. 899 INT Sec. 1
037 Comparator 2B, not/inverted 0, 1 CHAR
4)
0
038 Comparator 2C, limit -999999999 ..
999999999 LONG
1)
0 = 9,6kBit/s; 1 = 19,2kBit/s; 2 = 38.4kBit/s
2a)
0 = Pulse output, 1 = digital output, 2 = analog output, 3 = digital input,
4 = Profibus-Remote output, 5 = HT/NT changeover, real energie,
6 = HT/NT changeover, real energie and reactive energie.
2b)
0 = Pulse output, 1 = digital output, 2 = analog output, 3 = digital input,
4 = Profibus-Remote output, 5 = HT/NT changeover, reactive energie,
6 = HT/NT changeover, real energie and reactive energie.
3)
Min. pulse duration = setting range * 10 [ms]
4)
0 = higher than, 1 = smaller than
5)
Reading/writing 100=1,00
6)
0 = Comparator not used, 1 = remote, 200-424 = measured values
Parameter list
