TO ADJUST THE CLEARANCE BETWEEN THE NEEDLE AND THE FIXED NEEDLE GUARD
The clearance between the needle (A) and the fixed needle guard (B) should be 0.3 to 0.7mm
(3/256” to 7/256”).
TO ADJUST
1. Open the side cover and looper cover. Remove the presser foot and needle plate.
2. Bring the needle to the lowest position.
3. Loosen set screw (C). Adjust the fixed needle guard (B) by moving it back and forth.
The clearance between the needle (A) and the fixed needle guard (B) should be 0.3 to
0.7 mm (3/256 to 7/256’). Tighten set screw (C).
* Be careful not to move the fixed needle guard laterally (left or right).
4. Attach the needle plate and presser foot. Close the side cover and looper cover.
22
