46
z Turn the handwheel toward you to raise the needle
to its highest position.
Raise the presser foot lifter.
x Select the pattern “ ” by turning the pattern
selector dial.
If the BH pattern is already selected, reset the dial
once according to the procedure in ⁄2 (on page 46).
c Attach the automatic buttonhole foot (R).
v Pull the button holder to the back, and place the
button in it. Push back the button holder toward you
as far as it will go.
b Pull the buttonhole lever downward as far as it will
go.
q
Buttonhole lever
n Insert fabric under the foot.
Turn the handwheel slowly towards you with your
right hand until the needle goes down and continue
turning handwheel until the take-up lever is at its
highest position.
m Remove the fabric to the left to draw both threads to
the left.
, Insert the garment under the foot, and lower the
needle at the starting point.
Then lower the automatic buttonhole foot.
w
Starting point
NOTE: There should be no gap between the slider and
spring holder of the foot as shown above.
e
Slider
r There should be no gap
t Spring holder
Automatic Buttonhole
* The size of buttonhole is automatically set by placing
the button in the automatic buttonhole foot (R).
* The button holder of the foot takes a button size up
to 2.5 cm (1˝) in diameter.
* Make a test buttonhole on a sample duplicating the
fabric, interfacing and seams of the actual garment.
* Place the button on the fabric sample and mark the
top and bottom to determine the position of
buttonhole.
* Use interfacing on stretch fabrics.
q Stitch selector:
w Presser foot: R:Automatic buttonhole foot
e Thread tension: 1 – 5
r Stitch length: 0.5 – 1
t Stitch width: 5
qwe
rt
zxc
v
b
nm,
q
e
r
t
w
0
1
2
3
4
1
2
3
4
5
0
A
D
E
F
G
H
I
J
L
K
B
C
