Jasic TIG 315P Multi Wave - Page 18

A WILKINSON STAR LIMITED PRODUCT 01-19 ISSUE 1
Pin 2 is the common terminal of the potenometer. It uses the torch
control wheel 0 as the starng posion. When the current is the
minimum, the resistance of Pin 1 and Pin 2 is 10KΩ and the
resistance of Pin 2 and Pin 3 is 0Ω. When the wheel rotates to the
maximum and the current is the maximum, the resistance of Pin 1
and Pin 2 is 0Ω and the resistance of Pin 2 and Pin 3 is 10KΩ.
3. Connect the digital adjustable welding torch to Pin 4, Pin 5,
Pin 6, Pin 7, Pin 8 and Pin 9 of the torch switch aviaon socket
on the front panel of the welder through a special cable. Pin 4
-, Pin 5 +, Pin 6 2T/4T. Pin 7 has no connecon.
4. Under no load, press the remote buon to
turn on the indicator. The welding torch
enters the torch control mode.
5. Set the maximum welding current through the panel before
welding. Adjust the current by adjusng the welding torch
potenometer in the welding process. The adjustable range is
the minimum value to the set value.
6. When using the digital adjustable control torch, the
adjustment parameter can be switched through the
“Parameter Selecon” buon on the welding torch, and the
parameters can be adjusted through the “Para+” and “Para-”
buon, the “Torch switch” of the welding torch controls the
output mode.
Para-
Parameter
selecon
Torch switch
Para+
Digital adjustable control torch
Torch switch
Current
regulating
potentiometer
Analog adjustable control torch
Analog torch plug Digital torch plug
Cooler connecons
1. Pin 1 and Pin 2 are the 230VAC output terminals of the water cooler. Pin 3 and
Pin 4 are the error signal input terminals of the water cooler.
2. Under no load, press the water buon to turn on the
indicator. The machine then enters water cooling cycle mode
during welding.
3. Aer welding has ceased, the cooler will work for 5
minutes. If there is no welding in 5 minutes, the water cooler switches o
automacally.
