17
Other Electrical Accessories:
The Head lamp is fitted with a 12V-35/35 W double filament bulb with Ba 20d
Socket. The pilot bulb 6 V - I.5 W with Ba 9s socket is also fitted in the head lamp.
Tail lamp bulb - 6 V 5 W
Stop light bulb - 6 V 8 W
The electric Horn 6 V - 2 Amps fitted under the head lamp is fed by the battery
and is operated by a push button on the dip switch.
The H. T. Ignition coil is fitted to the frame underneath the fuel tank.
The condenser of value - 0.2 mF is placed on the frame in the vicinity of
the ignition coil. The condensor lead is connected to terminal No. 1 of the ignition
coil.
The sparking plug used either MICO HB - W 175 Zi or KLG F70. The stop light
switch is located in the R. H. side tool box.
Fig. 6. Stop switch diagram
All connections are of varnish coated automobile leads.
The lead terminals are brass or soldered. The leads from magneto to switch box;
dip switch to main bulb; and sparking plug leads have 1.5 mm
2
(0.002 sq. in) in
section and the remaining leads 1 mm
2
(0.0015 sq. in.).
