JAWA 353/04 User Manual

27
LUBRICATION CHART
Km
(Miles)
covered
Lubrication Point Point
No.
Total
Type of lubricant
Instructions
Indian Oil Castrol Shell Esso
500 Control lever pins (front brake,
clutch)
3 2 Mobil
Oil
BB
G.P.50
X-100
Motor Oil
50
Motor
Oil 50 2,3 drops with oil can
1000 Gear Box 4 1 Mobil
Oil
BB
G.P.50
X-100
Motor
Oil 50
Motor
Oil 50 Top-up after checking with level screw
1500 Rear Fork Pivot (Yezdi Model
‘B’ only)
2 1 Mobil
Grease
M.P
G.L.
Grease
Retinax
‘A’
Multi
Purpose
Grease
5 to 6 strokes of Grease Gun
3000 (a) Contact Breaker Arm Pin
(b) Speedometer drive cable
7
9
1
1
Mobil
Oil
BB
G.P.50
X-100
Motor
Oil 50
Motor
Oil 50
(a) Smear after removing arm
(b) 2 drops with oil can
(a) Contact Breaker Felt
(b) Twist Grip
7
8
1
1
Mobil
Grease
M.P
G.L.
Grease
Retinax
‘A’
Multi
Purpose
Grease
(a) Smear little with screw driver
(b) Remove, clean, smear and replace
3500 Gear Box 4 1 Mobil
Oil
BB
G.P.50
X-100
Motor
Oil 50
Motor
Oil 50 Drain and refill
(a) Wheel Bearings
(b) Rear Chain Wheel Bearings
6
15
2
1
Mobil
Grease
M.P
Heavy
Grease
Retinax
‘A’
Wheel
Bearing
Grease
Remove wheels; clean; repack bearings and refit
5000 Secondary Chain 10 1 Mobil
Grease
M.P
Graphite
Grease
Retinax
‘A’
Multi
Purpose
Grease
Remove; wash in kerosene; dry; submerge in molten grease; allow
to set; wipe surplus grease and refit
(a) Brake cams
(b) Control Cables
11
14
2
4
Mobil
Oil
BB
G.P.50
X-100
Motor
Oil 50
Motor
Oil 50
(a) 2,3 drops with oil can
(b) Disconnect cables; clean; lubricate and refit
8000 (a) Steering Head Bearing Balls
(b) Foot Brake Lever Pin
(c) Centre Stand Pin
16
17
13
2
1
1
Mobil
Grease
M.P
Heavy
Grease
Retinax
‘A’
Multi
Purpose
Grease
(a) Loosen stem; clean balls; repack and re-tighten
(b) Remove; clean; smear and replace
(c) Remove; clean; smear and replace
When
necessary
(a) Telescopic Front Fork
(b) Rear Suspension (non-
sealed type only)
5
12
2
2
Shock-
absorber
oil (light)
Shockol Donax
‘A’
Shock-
absorber
oil (light)
Drain, clean and refill: -
(a) with 175cc oil in each
(b) with 75cc oil in each
Always Engine 18 1 Mobil
Oil
BB
G.P.50
X-100
Motor
Oil 50
Motor
Oil 50
Mix with petrol in ratio 1:20 (1 litre oil 20 litres petrol)
IMPOTANT: During running-in period of first 1500 Kms ratio should
be 1:16
