AAA-055-00188
Jaylor Owner Manual -31- 5000 Series Truck Mount Models
General Mixing Issues
The following are some problems which the operator may be faced with at some point during cutting and
mixing. Remember, when performing any work on the mixer always park it on a flat, level surface, put
controls in neutral, apply the parking brake, stop the engine, remove the ignition key, and wait for all
moving parts to stop. Once it has completely stopped follow the below recommendations given to remedy
the problem.
Think SAFETY! Work SAFELY!
19.5.1 Feed Clogging
There are two common places that the feed will tend to clog. They are listed below along with guidelines
for unclogging:
1. The unloading door
• Open the door wider if possible and proceed with manual clean out
2. In the boot of the conveyor (only on left or right discharge options)
• Figure 13 shows where to open the conveyor to clean it out
