Replacement circuit breakers must be of the same voltage, amperage rating
and type. Never use a higher rated replacement circuit breaker; doing so may
cause a re by overheating the RV wiring.
Only replace circuit breakers with those of the same specied type, voltage, and current
rating.
Please contact your dealer for repair assistance when replacing circuit breakers.
At the beginning of camping season, inspect the circuit breakers and replace as needed. Test
by turning each circuit breaker “o” and back “on”. Circuit breakers are wearable parts and
must be replaced as needed, as part of your RV maintenance. If you have any questions,
consult your dealer.
A label is provided to explain the function of every 120-volt circuit breaker. This label is
located on or near the appropriate load center or sub-panel and must remain permanently
axed to the recreation vehicle.
Approximate Electrical Load Ratings
12 Volt System
Exterior Entertainment Center 5-7 AMPS
Fan 1.5 AMPS
Furnace 12.0 AMPS
gGenerator Start 95.0 AMPS*
Illuminated Switch .125 AMP
Inverter variable
Leveling sSystem 95.0 AMPS*
LP Detector .125 AMP
Light; hHalogen 1.7 AMPS
Light; Vanity 4.2 AMPS
Lights; Aisle 1.0 AMP
Lights; Baggage Compartment / Shower 1.4 AMPS
Lights; Decorative Wall / Map / Porch 1.5 AMPS
Lights; Fluorescent Double -12” 2.0 AMPS
Lights; Fluorescent Double -18” 2.5 AMPS
Power Awning 10.0 AMPS
Power Vent 5.0 AMPS
Refrigerator 3.0 AMPS
Step Cover 10.0 AMPS
TV Plate/Antenna Booster 1.0 AMP
Water Heater 6.0 AMPS
Water Pump 7.0 AMPS
*Momentary Load
12 Volts: Labeled watts divided by 12 = Power consumed in AMPS
