JBL CBT1000 - Attaching Speaker Brackets to System

4) ATTACH SPEAKER SIDE OF BRACKET TO SPEAKER
Option 4a) CBT 1000+1000E System with No Swivel
(for Down-Tilt Capability [or 0° tilt] and No Horizontal Swivel/Pan)
8 PLACES:
M8 x 20 mm
PAN HEAD
BOLT
M8 SPLIT
LOCK WASHER
M8
FLAT WASHER
Down-tilt range 0° to -5.25°
11
