JBL Cinema 300 - Page 38

38
Speaker System:
ScreenArray
TM
4622 (Bi-Amp)
Date: 3/4/2003
DSC260
Parameter
Input A
Input B
Input A+B
Input Delay
Input EQ1 Type Bell* Bell*
Input EQ1 Frequency 50.7 50.7
Input EQ1 +/- 3.0 3.0
Input EQ1 Bandwidth 0.60 0.60
Input EQ2 Type
Input EQ2 Frequency
Input EQ2 +/-
Input EQ2 Bandwidth
Input EQ3 Type
Input EQ3 Frequency
Input EQ3 +/-
Input EQ3 Bandwidth
Input EQ4 Type
Input EQ4 Frequency
Input EQ4 +/-
Input EQ4 Bandwidth
Input EQ4 Type
Input EQ4 Frequency
Input EQ4 +/-
Input EQ4 Bandwidth
Parameter
Output 1
Output 2
Output 3
Output 4
Output 5
Output 6
Output Name
USUSED
L LOW
L HI
UNUSED
R LOW
R HI
Output Source A A B B
Output Gain 0.0 -4.0 0.0 -4.0
Output Limit 10.0 10.0 10.0 10.0
Output Delay 0.792 0.000 0.792 0.000
Output Delay Link Off Off Off Off
Polarity Normal Normal Normal Normal
Output Lo Shape BUT12 BUT24 BUT12 BUT24
Output Lo Frequency 25.3 840.0 25.3 840.0
Output Hi Shape BUT24 BUT12 BUT24 BUT12
Output Hi Frequency 683.0 Out 683.0 Out
Output EQ1 Type Bell Bell Bell Bell
Output EQ1 Frequency 406.0 1.46k 406.0 1.46k
Output EQ1 +/- -5.5 -6.0 -5.5 -6.0
Output EQ1 Bandwidth 0.05 1.40 0.05 1.40
Output EQ2 Type Bell Bell Bell Bell
Output EQ2 Frequency 615.0 16.0k 615.0 16.0k
Output EQ2 +/- -9.0 15.0 -9.0 15.0
Output EQ2 Bandwidth 0.10 0.30 0.10 0.30
Output EQ3Type Bell Bell
Output EQ3 Frequency 9.18k 9.18k
Output EQ3 +/- -4.5 -4.5
Output EQ3 Bandwidth 0.60 0.60
Output EQ4 Type
Output EQ4 Frequency
Output EQ4 +/-
Output EQ4 Bandwidth
(*) Set this filter to "0.0dB" if system is installed in a full baffle wall
Page 1
Recommended signal processing settings for DSC260A Digital System Controller.
See www.jblpro.com for most current processor settings
