DSC Recommended Settings Cinema 5000
March 23, 1999
System
Output
5674
5672
5671
DELAY ms
A Subs 0.000 0.000 0.000
B Lows 1.656 1.656 1.604
C Mids 0.000 0.000 0.000
D Highs 1.854 1.854 1.739
Polarity [+] unless noted
EQ
A1 Frequency (Hz) Subs Not Used Not Used Not Used
Bandwidth in Octaves
dB
A2 Frequency (Hz) Subs Not Used Not Used Not Used
Bandwidth in Octaves
dB
B1 Frequency (Hz) Lows Not Used Not Used 203
Bandwidth in Octaves 0.4
dB
2
B2 Frequency (Hz) Lows Not Used Not Used Not Used
Bandwidth in Octaves
dB
C1 Frequency (Hz) Mids Not Used Not Used Not Used
Bandwidth in Octaves
dB
C2 Frequency (Hz) Mids Not Used Not Used Not Used
Bandwidth in Octaves
dB
D1 Frequency (Hz) Highs 9.18k 9.18k 11.7k
Bandwidth in Octaves 12 Hi Shelf 12 Hi Shelf 12 Hi Shelf
dB
5 5 7.5
D2 Frequency (Hz) Highs 2.82k 2.82k 3.36k
Bandwidth in Octaves 0.4 0.4 0.3
dB 2.5 2.5 -3.5
CROSSOVER
A Gain dB Subs Not Used Not Used Not Used
Limit*
Slope - low, hi
FR - low, hi Hz
B Gain dB Lows
0 3 5
Limit* 2.2 2.2 2.2
Slope - low, hi LR 24,LR24 LR 24,LR24 LR 24,LR24
FR - low, hi Hz 32, 297 32, 297 32, 366
C Gain dB Mids -10 -10 -14.5
Limit* -1 -1 -1
Slope - low, hi LR24, LR24 LR24, LR24 LR24, LR24
FR - low, hi Hz 297, 2.54k 297, 2.54k 297, 2.73k
D Gain dB Highs -9 -9 -11.5
Limit* -1 -1 -1
Slope - low, hi LR24, Out LR24, Out LR24, Out
FR - low, hi Hz 2.54k, Out 2.54k, Out 2.14k, Out
Note: Subwoofers are considered stereo. They can be summed to mono if desired.
* Limits are amplifier specific. Consult the Cinema 5000 owners manual for additional information.
