MS-8 Electrical Parts List
Part Number Description Qty Reference Designator or Application
Resistors
W-0701-1100-03 Resistor SMD 10Ω 1/10W ±1% 0603 1 R264
W-0701-1330-03 Resistor SMD 33Ω 1/10W ±1% 0603 7 R279,R294,R295,R296,R299,R320,R321
W-0701-4330-02 resistor array SMD 33Ω*4 1/10W ±5% 0603 10 RN1,RN2,RN3,RN4,RN5,RN6,RN7,RN8,RN9,RN10
W-0701-1101-03 Resistor SMD 100Ω 1/10W ±1% 0603 22
R3,R4,R41,R51,R190,R191,R192,R193,R194,R195,
R196,R197,R285,R286,R396,R397,R398,R399,R400,R401,
R402,R403
W-0701-1241-03 Resistor SMD 240Ω 1/10W ±1% 0603 10 R366,R335,R336,R345,R346,R347,R348,R355,R356,R365
W-0701-1681-03 Resistor SMD 680Ω 1/10W ±1% 0603 1 R232
W-07011698R003 Resistor SMD 698Ω 1/10W ±1% 0603 2 R52,R184
W-0701-1102-03 Resistor SMD 1KΩ 1/10W ±1% 0603 67
R28,R47,R48,R170,R204,R265,R266,R267,R268,R269,
R270,R271,R272,R275,R278,R322,R323,R325,R326,R327,
R328,R329,R330,R331,R332,R333,R334,R337,R338,R339,
R340,R341,R342,R343,R344,R349,R350,R351,R352,R353,
R354,R357,R358,R359,R360,R361,R362,R363,R364,R367,
R368,R369,R370,R371,R372,R384,R385,R386,R387,R388,
R389,R390,R391,R392,R393,R394,R395
W-0701-1152-03 Resistor SMD 1.5KΩ 1/10W ±1% 0603 8 R207,R210,R213,R216,R219,R222,R225,R228
W-0701-1182-03 Resistor SMD 1.8KΩ 1/10W ±1% 0603 8 R206,R209,R212,R215,R218,R221,R224,R227
W-0701-1222-03 Resistor SMD 2.2KΩ 1/10W ±1% 0603 8 R235,R237,R239,R241,R243,R245,R247,R249
W-0703124YK103 Resistor SMD 2.4KΩ 1/10W ±1% 0603 8 R236,R238,R240,R242,R244,R246,R248,R250
W-0701-1332-03 Resistor SMD 3.3KΩ 1/10W ±1% 0603 12 R55,R56,R59,R60,R63,R64,R67,R68,R276,R301,R310,R324
W-0701-1432-03 Resistor SMD 4.3KΩ 1/10W ±1% 0603 10 R2,R5,R373,R374,R375,R376,R377,R378,R379,R380
W-0701-1472-03 Resistor SMD 4.7KΩ 1/10W ±1% 0603 14
R7,R8,R26,R30,R202,R234,R252,R273,R274,R277,R280,
R287,R290,R291
W-0701-1512-03 Resistor SMD 5.1KΩ 1/10W ±1% 0603 4 R160,R164,R165,R251
W-0701-1103-03 Resistor SMD 10KΩ 1/10W ±1% 0603 61
R29,R31,R32,R33,R37,R40,R43,R45,R46,R50,R54,R57,
R58,R61,R62,R65,R66,R69,R70,R71,R72,R73,R74,R75,
R76,R77,R78,R79,R89,R91,R103,R158,R167,R169,R173,
R174,R186,R187,R189,R198,R199,R201,R205,R208,R211,
R214,R217,R220,R223,R226,R229,R230,R233,R283,R284,
R298,R382,R383,R34,R39,R297
W-0701-1243-03 Resistor SMD 24KΩ 1/10W ±1% 0603 1
R9
W-0701-1203-03 Resistor SMD 20KΩ 1/10W ±1% 0603 9 R254,R256,R257,R258,R259,R260,R261,R262,R263
W-0701-1402K03 Resistor SMD 402K 1/10W ±1% 0603 1 R168
W-0701136K5003 Resistor SMD 36.5KΩ 1/10W ±1% 0603 1 R253
W-0701148K7003 Resistor SMD 48.7KΩ 1/10W ±1% 0603 1 R300
W-0701-1473-03 Resistor SMD 47KΩ 1/10W ±1% 0603 1 R302
W-0701-1104-03 Resistor SMD 100KΩ 1/10W ±1% 0603 5 R255,R281,R231,R292,R293
W-0701-1474-03 Resistor SMD 470KΩ 1/10W ±1% 0603 2 R163,R38
W-0701-1475-05 Resistor SMD 475KΩ 1/10W ±1% 0603 23
R92,R93,R95,R96,R97,R98,R99,R100,R101,R102,R104,
R105,R106,R107,R108,R109,R166,R303,R304,R305,R306,
R171,R172
W-0701-1202-03 Resistor SMD 2KΩ
1/10W ±1% 0603 1 R288
W-07011221XK03
Resistor SMD 2.21K 1/10W ±1% 0603 2 R1,R6
W-07011232XK03 Resistor SMD 2.32KΩ 1/10W ±1% 0603 1 R80
W-07011768XK03 Resistor SMD 7.68KΩ 1/10W ±1% 0603 1 R81
W-0701-1267-03 Resistor SMD 2.67K 1/10W ±1% 0603 8 R53,R88,R90,R94,R177,R185,R188,R200
W-0701-1499-03 Resistor SMD 4.99K 1/10W ±1% 0603 1 R203
W-0701127R4003 Resistor SMD 27.4KΩ 1/10W ±1% 0603 1 R289
W-0701-1283-03 Resistor SMD 28KΩ 1/10W ±1% 0603 2 R175,R176
W-0701-1475-03 Resistor SMD 1/10W 47.5KΩ ±1% 0603 2 R27,R42
W-0701-1285-03 Resistor SMD 2.8M 1/10W ±1% 0603 1 R162
W-0701156K2003 Resistor SMD 56.2KΩ 1/10W ±1% 0603 16
R10,R11,R12,R13,R14,R15,R16,R17,R18,R19,R20,R21,
R22,R23,R24,R25
W-0701-1822-03 Resistor SMD 8.2KΩ 1/10W ±1% 0603 1 R307
W-0701-1634-03 Resistor SMD 63.4KΩ 1/10W ±1% 0603 1 R282
W-0701184K5003 Resistor SMD 84.5KΩ 1/10W ±1% 0603 16
R82,R83,R84,R85,R86,R87,R110,R111,R112,R113,R114,
R115,R116,R117,R118,R119
Capacitors
W-06S251056045 E-cap SMD 1uF/50V 4*5.4 ±20% 105℃ 3 C2,C28,C178
W-06S254754045 E-cap SMD 4.7uF/25V 4*5.4 ±20% 105℃ 13
C68,C90,C97,C108,C202,C211,C214,C233,C235,C237,
C256,C322,C324
