Part Number Description Qty Reference Designator or Application
W-ZA-H00010101 Bracket
248.6*38mm ADC-12 black texture
paint
2
W-DB-800010015 Lens
232*48*4MM PC transparency with
silkscreen and paint
1
W-SG-0002-0111 Top cover
294*162.4*52.5MM ADC-12 dia-
casting, silver paint and logo with
diamond cut
1
W-XG-0005-0101 Bottom
290.4*158.8*46.5MM ADC-12, dia-
casting, black texture paint
1
W-MK-0009-0101 Input Board
229.6*32.3mm SECC, 1.6t, black
texture paint with silkscreen
1
W-MK-0010-0101 Output Board
229.6*32.3mm SECC, 1.6t, black
texture paint with silkscreen
1
W-LS1AY0300601 Screw 3*6MM 9 Screw the PCBA, Input Board and Output Board to the bottom
W-LS1KM0040071 Screw 4*7MM 8 Screw the Bracket to the bottom
W-LS1AY0401201 Screw 4*12MM 4 Screw the top cover to the bottom
W-LS1BM0040081 Screw 4*8 MM 3 Screw the top cover to heatsink
W-1001-6500-10 HF inductor 65UH CL-7200 Φ30 1 L20
W-1360-0004-00 Tact Switch DIP 4PIN H=4.3MM TC00100 1 SW1
W-1400-0026-00 USB Jack DIP 4PIN USB-109 1 J5
W-1400-0028-00 Terminal JSZ4-01AN 1 TB1
W-1404-0006-00 RCA Jack
AV8-8.4-13AN(WR)8 Jacks, 16
PINS, black
1J7
W-1404-0008-00 RCA Jack
AV8-8.4-13AN(WR)8 Jacks, 16
PINS, White
1J2
W-1404-0028-02 RCA Jack
AV2-8.4-13AN(WR) 2 Jacks, 4
PINS, white and red
1 J11
W-1501-0800-00 Jack DIP 39-30-1160/3.96 8P 2 J3、 J6
W-1503-0700-00 needle stand
TM-2008-AG-14/2.54 14P( double
7P)
1J9
W-1401-0004-00 Fuse holder BXS-09 1 for F1
W-1601-253G-01 Fuse DIP 25A/32V LittelFuse 1 F1
W-1003-0004-08 Inductor SMD 1NH 0805 ±0.3NH 6 L17、L18、L19、 L21、L23、L24
W-1003-1500-00 Inductor SMD 15uH ±5% 2A SMRH74-150M 1 L22
W-18SM-2400-00 Crystal
SMD ASSVP-24.576MHZ-C04-T
ABRACONbrand
1Y1
W-1400-0024-00 Jack SJ-42524-SMT 1 J8
W-1400-0025-00 Microphone Jack SMD 5PIN Φ3.5mm Jack 1 J1
W-1004-1020-08 Inductor
SMD 1KΩ 0805 FBMA-11-201209-
102T
4 L25、L26、L27、L28
W-LS1AM0300607 Screw PM3*6 8
Screw the SUB Heatsink (A)/(B) to the PCBA
W-LS1BE0301607 Screw 3*16 6 Screw the SUB Heatsink A/B to the bracket
W-SR-MS80-0325 SUB Heatsink B
31*35*27.9MM Alum. Extrusion,
AL6063
1 Instal to the IC on the left side of the PCBA
W-SR-MS80-0425
SUB Heatsink A
98*35*27.9MM Alum. Extrusion,
AL6063
1 Instal to the IC on the right side of the PCBA
W-ZA-B00120100 IC Bracket A
31.5*23.1*10MM EGI,1.0T
/TDA3681
2 Instal to the SUB Heatsink A
W-ZA-B00130100 IC Bracket B 26.5*21.1*10MM EGI,1.0T/TDA7563 1 Instal to the SUB Heatsink B
W-ZL-10002A-35 LED Spacer 7.4*4.6*6.5 NYLON66 Black 1 Instal to the PCBA
W-LS1AJ0301001 Srew 3*10MM 9 Screw the RCA JACK/TRERMINAL to side board
W-JD-B40600515
tcp thermally
conductive pad
Φ12*3MM 3 Install to the screw hole of the bottom
MS-8
