JBL Incorporated Inc. 250 Crossways Park Dr. Woodbury, New York 11797
TECH TIPS
Troubleshooting tips and solutions to common service problems
For models: E150P,E250P TIP# JBLTT2003-04 Rev2
P10SW, P12SW
PB10,PB12 (Revision 2) *
Subject: Replacing MOSFETS Q18, Q22
In the event you need to replace MOSFET transistors Q18 or Q22 as part of a repair, it is
important to use ONLY:
• JBL part# 051-640001-000
• Or JBL part# FE106401110
• Or only the brands: International Rectifier, or Fairchild.
Replace both Q18 and Q22 MOSFET’s in the circuit, even if only one seems to be damaged.
Do NOT mix & match these components from different manufacturers, or batches. They should be
identical.
* Late version PB10 or PB12 subwoofers (Revision 2 in the service manual) can be identified by:
• Amplifier serial number starts with “HA”
• Output transistors in the open, on a large black heatsink
• Large plastic cup enclosing the rear of the amp assembly
• Main PCB, bottom, solder-side contains all SMD devices
E150P/P10SW subwoofers
