JBL Northridge E-Series E150P - 120 v Electrical Parts List

E150P/P10SW 120v Electrical Parts List
Part Number Description Reference Designator Qty
Resistors
020-000498-120 Carbon Film 0R 1/4W J R10,11 2
021-100401-120 MOF Resistor 1K 1W J R103 1
021-820303-020 MOF Resistor 820R 3WS J 8x20 R6,9 2
022-500003-020 KNP Resistor 0R05 3WS J FK TYPE R104 1
024-100298-120 SMD Resistor 10R 1/8W J 0805 R81,82 2
024-100398-120 SMD Resistor 100R 1/8W J 0805 R62 1
024-100498-120 SMD Resistor 1K 1/8W J 0805 65,79,83,92,95,96,105,108 8
024-100598-120 SMD Resistor 10K 1/8W J 0805 R2,37,54,58,63,69,71,72,74 9
024-100698-120 SMD Resistor 100K 1/8W J 0805 R3,112,22-25 6
024-110598-100 SMD Resistor 11K 1/8W F 0805 R98 1
024-113598-100 SMD Resistor 11K3 1/8W F 0805 R34 1
024-120498-120 SMD Resistor 1K2 1/8W J 0805 R51,53 2
024-130498-100 SMD Resistor 1K3 1/8W F 0805 R35,110 2
024-137598-120 SMD Resistor 13K7 1/8W F 0805 R42,43 2
024-137698-100 SMD Resistor 137K 1/8W F 0805 R32 1
024-150498-120 SMD Resistor 1K5 1/8W J 0805 R67,68,12-15 6
024-150598-120 SMD Resistor 15K 1/8W J 0805 R29 1
024-200598-120 SMD Resistor 20K 1/8W J 0805 R94 1
024-220398-120 SMD Resistor 220R 1/8W J 0805 R90 1
024-220498-121 SMD Resistor 2K2 1/8W J 0805 R1,87,61 3
024-220598-120 SMD Resistor 22K 1/8W J 0805 R50,52,118 3
024-220798-120 SMD Resistor 2M2 1/8W J 0805 R80,121 2
024-237598-120 SMD Resistor 23K7 1/8W F 0805 R48 1
024-237698-100 SMD Resistor 237K 1/8W F 0805 R45 1
024-243698-100 SMD Resistor 243K 1/8W F 0805 R36 1
024-270498-120 SMD Resistor 2K7 1/8W J 0805 R64,73 2
024-300398-120 SMD Resistor 300R 1/8W J 0805 R55 1
024-300598-120 SMD Resistor 30K 1/8W J 0805 R56 1
024-330498-120 SMD Resistor 3K3 1/8W J 0805 R7,8,59 3
024-330598-120 SMD Resistor 33K 1/8W J 0805 R4,5,122 3
024-332498-100 SMD Resistor 3K32 1/8W F 0805 R26,27 2
024-360498-120 SMD Resistor 3K6 1/8W J 0805 R28 1
024-390498-120 SMD Resistor 3K9 1/8W J 0805 R93 1
024-390598-120 SMD Resistor 39K 1/8W J 0805 R77 1
024-430498-100 SMD Resistor 4K3 1/8W F 0805 R78 1
024-453598-100 SMD Resistor 45K3 1/8W F 0805 R30 1
024-470298-120 SMD Resistor 47R 1/8W J 0805 R101,102 2
024-470398-120 SMD Resistor 470R 1/8W J 0805 R76,99,100 3
024-470498-120 SMD Resistor 4K7 1/8W J 0805 R85,86 2
024-470598-120 SMD Resistor 47K 1/8W J 0805 R44,47,49,107 4
024-470698-120 SMD Resistor 470K 1/8W J 0805 R70 1
24
E150P/P10SW subwoofers
