JBL Northridge E-Series E150P - Page 26

Part Number Description Reference Designator Qty
024-470798-120 SMD Resistor 4M7 1/8W J 0805 R60 1
024-560498-120 SMD Resistor 5K6 1/8W J 0805 R40,41 2
024-604598-100 SMD Resistor 60K4 1/8W F 0805 R39 1
024-620398-120 SMD Resistor 620R 1/8W J 0805 R16,18,57 3
024-680498-120 SMD Resistor 6K8 1/8W J 0805 R46,91 2
024-680598-120 SMD Resistor 68K 1/8W J 0805 R31,33,66 3
024-909498-100 SMD Resistor 9K09 1/8W F 0805 R38 1
025-010300-000 Thermister TSE-103 K L:50mm 1
026-200595-269 Freq Pot 20K PN:RD163121R03D-20KBx2(EJ) VR2 1
026-500495-252 Level Pot 5K PN:RK163111R52B-5KA (EJ) VR1 1
Capacitors
031-100244-100 Ceramic Capacitor 0u01/50V K 0805 X7R C5,10,33,45,51,66,67 7
031-100343-100 SMD Capacitor 100pF/50V J 0805 NPO C36,58,16 3
031-100344-100 SMD Capacitor 0u1/50V K 0805 X7R C11,42-44,46-49,52,54,55,60,63,71,74,77 16
031-100384-100R SMD Capacitor 0u1/250V K 1206 X7R C3,7 2
031-150244-100 SMD Capacitor 0u0015/50V K 0805 X7R C32 1
031-220344-100 SMD Capacitor 220pF/50V J 0805 NPO C20,21,19,14,15 5
031-330444-300 SMD Capacitor 3300pF/50V K 0805 X7R C40,34 2
031-470244-102 SMD Capacitor 0u047/50V K 0805 X7R C62,59 2
031-560243-100 SMD Capacitor 56pF/50V J 0805 NPO C57,61 2
031-560343-102 SMD Capacitor 560pF/50V J 0805 NPO C56 1
032-100464-202 Mylar Capacitor 1uF/100V K P:10 C70,70B 2
033-470444-270 NPE Capacitor 4u7/50V K10 (R)8x13 SBE C73 1
033-680464-270 NPE Capacitor 6u8/100V K10 (R)1020 GNE C72 1
034-100525-300 Electrolytic Capacitor 10uF/25V M (R)0511 P:5 C35 1
034-100625-300 Electrolytic Capacitor 100uF/25V M (R)6.3x11 P:5 C64 1
034-220525-301 Electrolytic Capacitor 22uF/25V M (R)5x11 P:5 C39,50,53,41,4,9 6
034-220615-301 Electrolytic Capacitor 220uF/16V M (R)0611 P:5 C37 1
034-330525-300 Electrolytic Capacitor 33uF/25V M (R)0511 P:5 C1 1
034-330615-300 Electrolytic Capacitor 330uF/16V M (R)0812 P:5 C12,78 2
034-470415-301 Electrolytic Capacitor 4u7/50V M (R)0511 P:5 C2 1
034-470615-301 Elect Capacitor (E150P) 470uF/16V M (R)0812 P:5 C65 (See service bulletin) 1
034-470515-200 Elect Capacitor (P10SW) 47uF/16V M (R)0812 P:5 C65 1
034-470745-200 Electrolytic Capacitor 4700uF/50V M (R)2236 C6,8 2
038-100363-300 MPE Capacitor 0u1/100V J C68,69,27 3
038-220393-300 MPE Capacitor 0u22/63V J C25-26,29,31 4
038-330393-300 MPE Capacitor 0u33/63V J C22,23,24 3
038-470293-300 MPE Capacitor 0u047/63V J C28,30 2
039-100384-100 Safety Capacitor HQX0.1K275VACx2 18x6x12mm CXAC1 1
Semiconductors
051-000600-100 NPN Transistor PN:MPSW06RLRA TO-92 Q2,Q16 2
051-003100-000 NPN Transistor PN:TIP 31C TO-220 (MOSPEC) Q4 1
25
E150P/P10SW subwoofers
