Part Number Description Reference Designator Qty
051-005600-100 PNP Transistor PN:MPSW56RLRA TO-92 Q3 1
051-222200-100 NPN Transistor PN:MPS2222ARLRA TO-92 Q21 1
051-290700-100 PNP Transistor PN:MPS2907A RLRA TO-92 Q19,23 2
051-540101-000 PNP Transistor PN:2N5401 TO-92 Q1 1
051-555100-000 NPN Transistor PN:2N5551 TO-92 Q17 1
051-640001-000 MOSFET N-Channel PN:IRF640N TO-220 (IR) Q18,22 2
052-400080-000 Bridge Regulator PN:RS804 400V,8A BR1 1
053-211100-000 IC;DIP,Driver PN:IR2111 Half-Bridge Driver U7 1
054-000100-100 SMD DIODE PN:ES1D 200V 1A D5,26,29,33,38 5
054-001002-100 SMD ZENER DIODE PN:BZX84C10 10V SOT-23 D35 1
054-001501-100 SMD ZENER DIODE PN:BZX84C15 15V SOT-23 D6,7,9 3
054-007200-100 SMD IC; (Dual OP-Amp) PN:TL072CDR SO-8 U5,6 2
054-007400-100 SMD IC;(Quad OP-Amp) PN:TL074CDR U2,3 2
054-011400-100 SMD Transistor PN:DTC114TKA SMT3 Q7 1
054-033904-100 SMD Transistor PN:MMBT3904LT1 SOT23 Q11,14,13,5,8,9 6
054-033906-100 SMD Transistor PN:MMBT3906LT1 SOT23 Q6,10,12,15 4
054-045580-100 SMD IC; (Dual OP=Amp) PN:NJM4558M-TE3 DMP-8 U4 1
054-050601-100 SMD ZENER DIODE PN:BZX84C5V6 5.6V SOT-23 D24,36,37 3
054-414803-100 SMD DIODE PN:LL4148 (Wishay) D1-4,8,10-23,27,30 21
054-540100-100 SMD Transistor PN:MMBT5401 LT1 SOT-23 Q20,24,26 3
054-555100-100 SMD Transistor PN:MMBT5551 LT1 Q25 1
050-505200-001 LED PN:LT-2402-21 D1B 1
Miscellaneous
065-050400-000 Sleeve φ3.5mm BLK F32 (125℃)
065-100200-000 UL Sleeve φ2.5 F32-2.5(blk) 125℃
082-022640-000 Wire Set #26 UL1007 L=400mm blk/wht 2P Hsing +5TT
091-000182-000 LED Holder PN:LED5-2A
041-115001-000 Bead Coil YT-10911 L5 1
042-010052-003 Transformer YT-10615-4 PT1 1
043-300101-000 Inductor 30uH YT-10033 L2 1
043-324300-000 Inductor 324uH YT-10778 L4 1
043-560200-000 Inductor 56uH YT-10779 L1 1
043-700101-000 Toroidal Inductor 70uH YT-10682 L3 1
044-100100-000 SMD Ferrite Bead PN:321611 600R/100MHz 1206
061-020000-000 Knob ABS φ20x15m/m UL94V-0 BLK
061-314002-000 Strain Relief P/N SB4F-2
061-400014-000 Rubber Foot ID:6.2 OD:11.5 t=2mm blk
061-700044-000 Mycar 13x18mm TO-220
063-010012-000 Bracket for pwr trans P/N:TRK-1
063-321101-000ZR Amp Faceplate E150P 322x105.7x15mm BLK (94V0)ABS 1
063-321100-001ZR Amp Faceplate P10SW 322x105.7x15mm BLK (94V0)ABS 1
063-531808-000 Bucket 322x105.7x146.5mm BLK (94VO) 1
071-100608-100 Fiber washer OD=8mm ID=3.2 t=1 (red)
071-100851-000 Washer ID=5.1 OD=12 t=1m/m
072-010007-000 RCA Jack SCJ-1020 2P(G) wht,red
072-040039-000 Terminal PC205 (t=0.8m/m) T205MA
26
E150P/P10SW subwoofers
