Part Number Description Reference Designator Qty
072-040064-000 Terminal PC250(t=0.8),T250MA
072-040096-000 Terminal (t=0.8mm) PC187(0.8)
072-040169-000 Connector 2 PIN JS-1001-2 P:2.5mm
072-060170-000 B.P. W / Accessory parts
073-032316-601 Black anodized 70x42x20mm
073-050001-000 Fuse Clip P/N:CFFH1206
074-020018-000 Rocker SW PN:RF1003-BB4-0
074-030002-000 Toggle SW PHASE PN:L101-T2B4QE SW5 1
074-300018-000 Relay PN:943-1C-48D K1 1
082-022241-001 Wire set #22 UL1007 L=410mm blk/wht
083-041802-009 UL Power Cord SPT-2 blk #18 T187
093-205209-300 Fuse 1.25A 250V 5x20mm F1 1
181-911600-161 Wire #16AWG UL1007 blk L=610mm T205
181-911655-135 Wire #16AWG UL1007 green L=610mm T250
181-921600-000 blk wire #16 UL1015 T187 L:140mm
181-921699-000 wht wire #16 UL1015 T187 L:160mm
008-061215-000 Gasket C4305 12x15 t=5mm CR
008-062002-002 Gasket L-32 200x20mm t=5mm PORON
008-062002-012 Gasket 200x20mm t=2mm CR4305
008-063208-000 Gasket C4305 321x8 t=1mm CR
008-069304-000 Gasket C4305 93x4 t=1mm CR
27
E150P/P10SW subwoofers
