Technical Data
Static Dimensions
129 9831/7750-1 129
Technical Data
Static Dimensions
Dimensions
For: CT160 ............................................................................................................................. Page 129
For: CT260 ............................................................................................................................. Page 130
(For: CT160)
Figure 77.
Table 14.
Item Description CT160-80 CT160-100
A Wheelbase 1,560 mm 1,560 mm
B Overall width 960 mm 1,090 mm
C Drum diameter 580 mm 580 mm
D Height to the top of seat 1,650 mm 1,650 mm
E Height with ROPS (Roll-Over
Protective Structure)
2,485 mm 2,485 mm
F Ground clearance 255 mm 255 mm
G Kerb clearance 510 mm 510 mm
H Total travel length 2,140 mm 2,140 mm
J Drum thickness 12 mm 12 mm
K Drum width 800 mm 1,000 mm
