Operation
Fire Extinguisher
54 9831/7750-1 54
Fire Extinguisher
General
The fire extinguisher cab be stowed in a bracket on the ROPS (Roll-Over Protective Structure) frame at the back
of operator seat. Keep the fire extinguisher in the bracket until you need to use it. Refer to: Main Component
Locations (Page 9).
Operation
WARNING Do not use the fire extinguisher in a confined space. Make sure that the area is well ventilated
during and after using the fire extinguisher.
WARNING After any use, the extinguisher must be replaced or serviced.
Make sure that you understand how to use the fire extinguisher. If necessary, refer to the instructions found
on the fire extinguisher.
Only try to extinguish a fire if the circumstances permit and your safety is not endangered. If necessary, contact
your nearest fire department.
Using the fire extinguisher:
1. Move the machine to a safe area to prevent the fire from spreading.
2. Remove the fire extinguisher from its bracket.
3. Aim directly at the fire from an upwind position, if possible.
4. Squeeze the trigger to operate the fire extinguisher, release the trigger to stop the flow. Refer to Figure 30.
Figure 30.
A Trigger
