Operation
Instruments
47 9831/7750-1 47
Table 5.
A Battery charging condition Audible/Visual. The lamp illuminates and buzzer will sound,
if battery is not charging while engine is running. If battery is
charging, the lamp and buzzer should go off a few seconds af-
ter the engine is started.
B Engine low oil pressure Audible/Visual. Illuminates if the engine oil pressure drops too
far. Illuminates when the ignition switch is set to position 'I' be-
fore starting the engine but should extinguish when the engine
starts, if this light remains 'on' stop the engine immediately.
C High coolant temperature Audible/Visual. The light will illuminate when the engine
coolant temperature is too high. Stop the machine immediately
and remedy the fault.
D Direction indicator Visual only. Illuminate with the direction indicators. Use the di-
rection indicators to signal before you turn the machine.
E Hazard warning indicator Visual only. Flashes with the hazard warning lights. Turn the
flashers on when your machine is a possible hazard.
F Main beam Visual only. Lights up when the headlight main beams are
switched on. Turn the main beams off for on-coming traffic.
G Water in fuel Visual only. Illuminate when water in fuel is detected.
H Water sprinkler Visual only. Illuminate when water sprinkler is on.
J Neutral Visual only. Illuminate when driver lever is in neutral position.
K Seat switch Visual only. Illuminate when operator is not sat on the operator
seat.
L Parkbrake on Visual only. Illuminates when the park brake is engaged.
M Hydraulic oil filter Visual only. Illuminate when hydraulic oil filter is blocked.
N Engine air filter blocked Audible/Visual. Illuminate engine air filter is blocked.
P Engine pre heat Visual only. Illuminate when engine pre heat is on.
