60 - 1
Schematic
Section E
Hydraulics
9803/6400
Section E
60 - 1
Issue 3*
Stacked (Slew Brake) Valve
Solenoid Part
V
alve Part
1. Voltage
DC24V
1. Working Pressure
3.9 MPa (40 kgf/cm
2
)
2. Consumed Power
12W
2. Working Flow
16 l/min
3. Other
Surge Suppressor
3. Decompressor Pressure
JS200/240
Pressure
1.5
+0
MPa
(15
+0
kgf/cm
2
)
*
333
335
