Section F
Transmission
9803/6400
Section F
1 - 1
Issue 3*
Torque Specifications
Torque Specifications JS200/JS240
Component Nm kgfm lb/ft Remarks
Traction motor 266.6 - 311.6 27.2 - 31.8 196 - 229.9 Apply 262
Locating Bolts
Component Nm kgfm lb/ft Part No. Remarks Qty
Plug 118 ±5.9 12 ±0.6 86.76 ±4.3 2-14,-17 PF
1
/
2
1,1
Orifice 2.45 ±0.49 0.25 ±0.05 1.8 ±0.36 2-22,-23 2,2
Plug 9.8 ±1.0 1.0 ±0.1 7.23 ±0.72 2-8 NPTF
1
/
16
10
Plug 118 ±5.9 12 ±0.6 86.76 ±4.3 2-17 1
Cap Assy 373 ±20 38 ±2 274.7 ±14.46 2-6 2
Nut 37.2 ±4.7 4.0 ±0.5 28.92 ±3.6 2-16 1
Socket Head Bolt 108 ±10 11 ±0.1 79.5 ±7.23 2-6.5 4
Plug 137 ±10 14 ±1 101.2 ±7.23 2-2.4 2
Plug 9.8 ±1.0 1.0 ±0.1 7.23 ±0.72 2-8 NPTF
1
/
16
10
Plug 29.4 ±2.9 3 ±0.3 21.6 ±2.16 2-19 PT
1
/
4
5
Plug 39.2 ±4.9 4 ±0.5 28.9 ±3.61 2-24 PT
3
/
8
1
Orifice 2.45 ±0.49 0.25 ±0.05 18 ±0.36 35 M5 1
Plug 9.8 ±1.0 1.0 ±0.1 7.23 ±0.72 34 NPTF
1
/
16
5
Plug 7.8 ±1.0 0.8 ±0.1 5.78 ±0.72 28 PT
1
/
8
1
Plug 12.3 ±2.5 1.25 ±0.25 9.03 ±1.8 27 PT
1
/
4
1
Bolt socket head 191 ±15 19.5 ±1.5 140.9 ±10.8 21 16
Plug 58.8 ±4.9 6 ±0.5 43.38 ±3.6 26 PT
1
/
2
3
Bolt socket head 58.8 ±4.9 6 ±0.5 43.38 ±3.6 25 16
Bolt socket head 294 ±19 30 ±2 216.9 ±14.46 16 4
Bolt socket head 417 ±25 42.5 ±2.5 307.27 ±18.07 17 16
Bolt socket head 108 ±10 11 ±1 79.5 ±7.23 20 13
Relief valve 373 ±20 38 ±2 274.74 ±14.46 2-6 2
Traction Motor
This table refers to the Traction Motor sectional drawing
*
