5 - 6
Attachments
(continued)
Bucket and Dipper Installation JS240,
JS240LC
Section B
Body & Framework
9803/6400
Section B
5 - 6
Issue 2*
Maintenance Specifications
*
Equipment Part
Code
Standard
Service
Name
Name
Value (mm)
Limit (mm)
11.
Bucket and
Bucket
a
326
323
Dipper
installation
Dipper b
325
323
Clearance
c
1.0-3.5
Bushing
d
16
8
(bucket)
Pin
e
ø90
ø89
Bushing
f
ø90
ø91.5
(bucket)
Bushing
g
ø90
ø91.5
(bucket)
Shim for
adjustment
KBV0713
86
88
