76 - 2
Section E
Hydraulics
9803/6400
Section E
76 - 2
Issue 2*
Hydraulic Rams
Reconditioning (continued)
Bushing press-fitting jig
a. Jig components
Note: The above Part No. indicates those for rod diameter 80 mm.
b. Special characteristics
If this special jig is used, anyone can press-fit the bushing into cylinder head quickly, easily and accurately without damaging
the cylinder head.
Wiper ring press-fitting jig
a. Jig components
Note: The above Part No. indicates those for rod diameter 80 mm.
b. Special characteristics
By using this special jig, anyone can press-fit the wiper ring easily, quickly and accurately into the specified groove of the
cylinder head evenly without deforming or damaging it.
Cylinder head insertion guide jig
a. Jig components
Note: The above Part No. indicates those for rod diameter 80 mm.
b. Special characteristics
By using this special jig, anyone can slide the cylinder head assembly onto the piston rod quickly, easily and accurately without
damaging any of the seals.
Part no Part Name Qty Note
WDB 2166 Bushing press-fitting jig set 1 Also to be used for removing bushing
Chuck assembly 1
WDB 2166-1 Retainer 1 Also to be used for press-fitting wiper ring
Part no Part Name Qty Note
WDB 2166-1 Jig for press-fitting wiper ring 1 Also to be used for removing bushing
(Retainer)
Part no Part Name Qty Note
WDB 2174 Cylinder head insertion guide jig 1
*
*
*
To Next Page
