jcb JS210 Service Manual

76 - 4
Section E
Hydraulics
9803/6400
Section E
76 - 4
Issue 1
Hydraulic Rams
Reconditioning (continued)
For press-fitting wiper ring (Can be used for pulling out and press-fitting bushing)
Note: The mark O in the table below indicates KCH type.
Note: The jig for press-fitting the wiper ring can also be used for pulling out and press-fitting the bushing.
The jig is set for KCH type only.
Jig for inserting cylinder head
Note: The mark O in the table below indicates KCH type.
Note: The jig is set for the KCH type only.
Piston rod diameter Unit: mm
50 55 60 65 70 75 80 85 90 95 100 105 110
Boom O
Dipper O
Bucket O
Boom O
Dipper O
Bucket O
Boom
Dipper
Bucket
Jig No.
WDB 2165-1 WDB 2166-1 WDB 2167-1 WDB 2168-1 WDB 2169-1 WDB 2170-1 WDB 2171-1 WDB 2172-1
JS200/
200LC
JS240/
240LC
Piston rod diameter Unit: mm
50 55 60 65 70 75 80 85 90 95 100 105 110
Boom O
Dipper O
Bucket O
Boom O
Dipper O
Bucket O
Boom
Dipper
Bucket
Jig No.
WDB 2173 WDB 2174 WDB 2175 WDB 2176 WDB 2177 WDB 2178 WDB 2179 WDB 2180
JS200/
200LC
JS240/
240LC
